Bidirectional power modules for Renewables projects

Why Choose Watt & Well’s Bidirectional Power Modules?





CE & UL compliant

Our power modules meet international standards and are field-proven by European and US EV charging manufacturers

Pioneer in bidirectional power module technology

Used in Groupe RENAULT’s first full-scale V2G experiments (Utrecht & Porto Santo, 2019)

6+ years of development

Expertise inherited from V2G innovation programs, focused on grid-tied power converters

European leadership

Active role in the Archimedes project and multiple pilot programs across the continent

AC bidirectional power module.



Power Modules 11 KW BMPU

Designed for smart grid (V2G, V2H, V2L) applications, BMPU-R2 is a modular grid-tied power supply capable of bidirectional conversion between AC (grid) and DC (EV battery). Its innovative 4-phases design enables operation in three-phase 16A (with or without neutral) or single phase 32A. This module supports 3 modes: G2V (charging battery from grid), V2G (discharging battery into the grid), V2L (creating AC grid using battery power).

BMPU-R2 is the latest generation of our greatly renowned BMPU series of V2G converters, deployed as part of the Smart Fossil Free island (with Renault at Porto Santo).

As a high-performance bidirectional power module, the BMPU-R2 has earned the European Council’s “Seal of Excellence,” with four patent filings under the IPA4SME program — a testament to its innovation and impact in the field of smart mobility and renewable integration.

SEE BMPU-R2 DATASHEETVDE CERTIFICATE
EU DECLARATION OF CONFORMITYAPPLICATION NOTE DC EV CHARGING STARTUP SEQUENCE

APPLICATION NOTE INTERFACING WITH CAN BUSAPPLICATION NOTE PYTHON TOOL FOR SOFTWARE UPGRADE

APPLICATION NOTE QUICK START GUIDEAPPLICATION NOTE PARALLEL AND SERIES OPERATIONS

  • Features
    • Active and reactive grid power regulation
    • Compliance with IEC 61851-1(ed 3.0), IEC 61851-23 (ed 1.0), IEC 61000-6-1/2/3/4
    • Tested according to: EN 50549-1:2019 , VDE-AR-N 4105 and IEEE-1547-2003
    • Integrated fuses (DC)
    • Integrated forced air cooling with fan speed control
    • Integrated protections including AC and DC pre-charge, OCP, OTP and UVLO
    • CANopen compatible digital bus with advanced monitoring
    • Advanced metering on each phase
    Dimensions 19” rack, 2U, 360.6mm depth
    (448.4 x 360.6 x 88 mm converter without handles)
    AC side 400-480VAC/50-60 Hz
    ● Three-phase operation with or without neutral (up to 16Amrs)
    ● Single phase operation (up to 32Arms)
    DC side 250-500 V
    DC current ±32A
    Output power ±11kVA
    Efficiency Up to 95%
    Power factor Programmable
    Operating temperature -10°C to 70°C

PCS-100 Power Module

Designed for Battery Energy Storage Systems (BESS), PCS-100 is a high-efficiency bidirectional power module rated at 100 kW, operating as a string inverter between the AC grid and DC battery. Its modular design allows parallel operation and can be used as a part of a high power system reaching up to several megawatts. The converter supports two modes of operation: On-Grid (charging and discharging the battery to the grid) and Off-Grid (creating AC grid from battery power).

SEE PCS-100 DATASHEET



  • Key advantages of string inverters
    • Reduced Installation and maintenance costs

        – Thanks to their modular design, the products are easy to handle and transport.
        – Designed for convenient servicing, the system allows quick replacement of defective components.

      • Power optimization through precise monitoring
        – Maximize conversion efficiency by smart power allocation.
        – Rack level current balance control.

      • Maximum Flexibility
        – Power output can be scaled to match container size.
        – Ideally suited to have an easy product scalability.
    • Features
      • Grid configuration: 3-Phase with or without neutral depending on version
      • Designed to be compliant with grid codes
      • Designed to be compliant with IEC 62477-1 and UL1741
      Dimensions 19” rack, 2U
      Communication protocol CANOpen and Modbus TCP/IP communications
      Output voltage 1500VDC/110A
      Output current  83Arms max
      Output power 99kW at 690Vrms, 57kW at 400Vrms
      Efficiency Up to 99%
      Response time < 20 ms
      Cooling system Liquid cooling
      Grid Voltage 400-730VAC/50-60 Hz

    DC power module for bidirectional charging.



    Power Module 11 KW BMPU

    The BMPU-R2-DC is a 11 kW Bidirectional Power Unit, DC/DC isolated converter capable of bidirectional conversion between a DC grid and an EV battery.

    It features a modular design capable of parallel operation and can be used as a part of a very high power system.

    Typical application: electric vehicle supply equipment (EVSE) supplied by ESS or DC grid.

    SEE BMPU-R2-DC DATASHEET



    • Features
      • Grid power regulation, EV battery current and voltage regulation.
      • Compatibility with IEC 61851-1(ed 3.0), IEC 61851-23 (ed 1.0)
      • Compatibility with CurrentOS standard for DC grids
      • Integrated fuse on EV battery side
      • Integrated forced air cooling with fan speed control
      • Integrated protections including pre-charge on EV battery side, OCP, OTP and UVLO
      • CANopen compatible digital bus with advanced monitoring



        Dimensions 19” rack, 2U, 360.6mm depth
        (448.4 x 360.6 x 88 mm converter without handles)
        Grid DC voltage 500 V (800V for -HV version)
        EV DC voltage 500 V
        EV DC current ±32A
        Output power ±11kW
        Efficiency Up to 95%
        Operating temperature -10°C to 70°C
